R25

R25



Engine: 4 Step, 8 valve DOHC liquid-cooled, two-cylinder.
Bore x Stroke: 60.0 x 44.1 mm,
Compression ratio: 11.6: 1,
Fuel system: fuel injection,
Ignition system: TCI (Transistorized Ignition Control)
Type of spark plug: CR9E
Battery Type: GTZ8V (MF Battery 7.4 Ah)
starter system: electric starter
Lubrication system: Wet
Dimensions; length x width x height (2,090 mm x 720 mm x 1,135 mm)
Seat height: 780 mm
Ground clearance: 160 mm
Wheel base: 1380 mm
Caster angle: 25 degrees
Trail: 95 mm
Maximum power: 26.5 kW (36 PS) 12 thousand RPM
Maximum Torque: 22.6 Nm 10 thousand RPM
Fill Weight: 166 kg
Tank Capacity: 14.3 L (Res: 3 L)
Type of housing: Diamond
Type of transmission: manual, 6 speed
Type clutch: Wet, manual clutch, Multiplat
Front and rear tires: Tubeless 110/70-17M/C (54s) & 140/70 - 17M / C (66s)
Front suspension: telescopic fork (diameter 41 mm)
